Think differently about human machine interfaces (HMIs)

Eaton’s revamped XV300 series of human machine interfaces feature embedded Linux operating system and new hardware offering extremely fast processing while complying with the latest cyber security standards. The XV300 series of (HMIs) enhances the field of automation with contemporary control interfaces and command methods common in today’s touchscreen devices. High system performance and a powerful graphic processor allow user interfaces to be implemented, meeting and exceeding expectations with features like fast screen changes and integrated, multimedia elements. XV300 devices are equally suitable for use as HMI operator panels and as HMI-PLC units with integrated PLC functionality.

Contact me about this product

Machinery control training Eaton industrial control line card Cybersecurity information and disclaimer

Overview Models Resources Support

XV300 human machine interface (HMI) core features

HMI / PLC devices with identical mechanical dimensions as predecessor system.
Wide range of interfaces similar to predecessor system: Ethernet, CAN, RS232, RS485, USB-Host and SD-Card
Embedded Linux operating system with advanced cyber security features
Sleek, tablet-like design with capacitive multi-touch technology (PCT)
High-resolution widescreen display sizes 7”, 10.1”and 15.6”

Heavy-duty, easy-to-clean front with toughened and anti-reflective glass
Powerful CPU: 800 MHz ARM Cortex-A9 with high-performance graphics processing unit
1 GB internal memory, 128 KB retain memory for PLC, 512 MB RAM
A variety of certifications: CE, cUL, cUL Class1 Div2, ATEX Zone 22; for 15” units cUL in preparation
Maritime Classification Society: DNV-GL (Environmental Category C, EMC1); for 15” units DNV-GL in preparation

Scalable software solutions

Name: XV300 advanced human machine interface (HMI)
Brand: Eaton

Galileo

Galileo is an intuitive and powerful engineering environment that takes little time to master. This versatile software meets basic requirements involved in today’s on-machine operation. It is tailored to the needs of system integrators and reflects the latest in visualization technology.

HTML5-based remote access enables access to the runtime with common browsers such as Chrome and Safari.

Find out more about Galileo

CODESYS

CODESYS is used to implement PLC functions directly in the HMI. When implemented as an efficient HMI-PLC combination, CODESYS enables users to develop powerful and comprehensive programming functions in line with the IEC 61131 international standard. In fact, with sophisticated technical features, ease of use, and the software’s growing popularity as a programming system for automation components from a wide variety of manufacturers, it is no surprise that it has become the system of choice for many machine builders.

Find out more about CODESYS.

XV300 series HMI and HMI-PLC

Think differently about human machine interfaces

The evolution of the HMI is here:

Heavy-duty – Compact and sleek design, featuring a heavy-duty, flat, anti-glare toughened glass panel, these panels are ideal for harsh industrial environments.
Powerful – High-performance and graphics co-processing unit make it possible for our XV300 to have highly responsive state-of-the-art user interface and allows for the integration of media elements such as video, PDF and web content.
Gestures – Gestures support allows for easily navigating complex menu screens. Flick to scroll through parameter lists, swipe left or right to change pages, or swipe up and down to reveal hidden menus. All of these features allow new design elements that will maximize the functionality and screen space on the machine.
